• Widened tread design, long wear life.
• Perfect combination of TMS technology and special compound, better wear resistance.
• Shanxi Pingyao field test data shows clear where performance improvement.
Size |
PR | Loading Index |
Speed Rating |
Tread Depth |
Rim Width |
Alternative Rim | New Tire Inflated Dimensions (mm) | Max Load (Kg) |
Pressure (KPa) |
Tube |
Static Radius Under Load |
Min. Dual Tire Space | |||
10.00R20 | 18 | 149 | 146 | K | 16.5 | 7.50 | 8.00 | 278 | 1054 | 3250 | 3000 | 930 | TT | 486 | 328 |
11.00R20 | 16 | 150 | 147 | K | 17.5 | 8.00 | 8.50, 8.00V | 293 | 1085 | 3350 | 3075 | 830 | TT | 499 | 346 |
11.00R20 | 18 | 152 | 149 | K | 17.5 | 8.00 | 8.50, 8.00V | 293 | 1085 | 3550 | 3250 | 930 | TT | 499 | 346 |
12.00R20 | 18 | 154 | 151 | K | 17.0 | 8.50 | 8.50V, 9.00 | 315 | 1125 | 3750 | 3450 | 830 | TT | 516 | 372 |
12.00R20 | 20 | 156 | 153 | K | 17.0 | 8.50 | 8.50V, 9.00 | 315 | 1125 | 4000 | 3650 | 900 | TT | 516 | 372 |
12.00R20 | 22 | 158 | 155 | J | 17.0 | 8.50 | 8.50V, 9.00 | 315 | 1125 | 4250 | 3875 | 970 | TT | 516 | 372 |
315/80R22.5 | 18 | 154 | 151 | M | 17.0 | 9.00 | 9.75 | 312 | 1076 | 3750 | 3450 | 830 | TL | 500 | 351 |
315/80R22.5 | 20 | 157 | 154 | L | 17.0 | 9.00 | 9.75 | 312 | 1076 | 4125 | 3750 | 900 | TL | 500 | 351 |
11R22.5 | 16 | 146 | 143 | M | 16.5 | 8.25 | 7.50 | 279 | 1054 | 3000 | 2725 | 830 | TL | 491 | 318 |
12R22.5 | 16 | 150 | 147 | L | 17.5 | 9.00 | 8.25 | 300 | 1085 | 3350 | 3075 | 830 | TL | 504 | 342 |
12R22.5 | 18 | 152 | 149 | K | 17.5 | 9.00 | 8.25 | 300 | 1085 | 3550 | 3250 | 930 | TL | 504 | 342 |
13R22.5 | 18 | 156 | 153 | L | 17.0 | 9.75 | 9.00 | 320 | 1124 | 4000 | 3650 | 875 | TL | 521 | 350 |
