• Wide shoulder block, increased handling performance.
• Improved rib design in shoulder groove, Good prevention for irregular wear.
• Center rib pattern design, good steering precision and straight line driving.
• Small grooves and sipes design, improved shock-absorbing, good ride comfort and handling.
Size |
PR |
Loading Index |
Speed Rating | Tread Depth(mm) |
Standard Rim |
Alternative Rim | Section Width(mm) | Overall Diameter(mm) | Max Load(kg) |
Pressure (KPa) |
Tube | |
235/75R15 ** | - | 105 | H | 8.7 | 6½J | 6J, 7J, 7½J, 8J | 235 | 733 | 925 | 350 | TL | |
235/70R15 ** | - | 107 | H | 8.7 | 7J | 6½J, 7½J | 240 | 711 | 975 | 340 | TL | |
225/70R15 | - | 108 | T/S | 8.7 | 7½J | 7J, 8J | 260 | 739 | 1000 | 350 | TL | |
215/65R16 | - | 98/102 | T | 8.2 | 6½J | 6J, 7J, 7½J | 221 | 686 | 750/850 | 350/340 | TL | |
* | ||||||||||||
215/70R16 | - | 100/104 | T | 8.7 | 6½J | 5½J, 6J, 7J | 221 | 708 | 800/900 | 350/340 | TL | |
* | ||||||||||||
235/60R16 | - | 100 | T | 8.7 | 7J | 6½J, 7½J, 8J, 8½J | 240 | 688 | 800 | 350 | TL | |
* | ||||||||||||
235/70R16 | - | 106 | T | 8.7 | 7J | 6J, 7J, 7½J | 240 | 736 | 950 | 350 | TL | |
* | ||||||||||||
245/70R16 | - | 107 | T | 8.7 | 7J | 6½J, 7½J, 8J | 248 | 750 | 975 | 350 | TL | |
* | ||||||||||||
245/75R16 ** | - | 111 | H | 8.7 | 7J | 6½J, 7½J, 8J | 248 | 774 | 1090 | 350 | TL | |
255/70R16 | - | 111 | T | 8.7 | 7½J | 7J, 8J | 260 | 764 | 1090 | 350 | TL | |
215/60R17 | - | 96 | H | 8.2 | 6½J | 6J, 7J, 7½J | 221 | 690 | 710 | 350 | TL | |
* | ||||||||||||
225/60R17 | - | 99 | H | 8.7 | 6½J | 6J, 7J, 7½J, 8J | 228 | 702 | 775 | 350 | TL | |
* | ||||||||||||
225/65R17 | - | 102 | T | 8.7 | 6½J | 6J, 7J | 228 | 724 | 850 | 350 | TL | |
* | ||||||||||||
235/55R17 | - | 99/103 | H | 8.2 | 7½J | 7J, 8J | 245 | 690 | 775/875 | 350/340 | TL | |
* | ||||||||||||
235/60R17 | - | 102 | H | 8.2 | 7J | 6½J, 7½J, 8J, 8½J | 240 | 714 | 850 | 350 | TL | |
235/65R17 | - | 104 | T | 8.7 | 7J | 6½J, 7½J, 8J, 8½J | 240 | 738 | 900 | 350 | TL | |
* | ||||||||||||
245/65R17 | - | 107/111 | T | 9.7 | 7J | 6½J, 7½J | 248 | 750 | 975/1090 | 350/340 | TL | |
* | ||||||||||||
225/60R18 | - | 100 | V | 8.2 | 6½J | 6J, 7J | 228 | 727 | 800 | 350 | TL | |
235/60R18 | - | 103 | V | 8.2 | 7J | 6½J, 7½J, 8J, 8½J | 240 | 739 | 875 | 350 | TL | |
* | ||||||||||||
235/55R18 | - | 100 | V | 8.2 | 7½J | 7J, 8J | 245 | 715 | 800 | 350 | TL | |
* | ||||||||||||
255/55R18 | - | 105/109 | H/V | 8.2 | 8J | 7½J, 8½J | 265 | 737 | 925/1030 | 350/340 | TL | |
* | ||||||||||||
285/60R18 | - | 116 | H | 9.2 | 8½J | 8J, 9J, 9½J, 10J | 292 | 799 | 1250 | 350 | TL | |
* Available in EU | **To be made available in 2015 | |||||||||||
