Tire Size Designation |
Pattern |
Star Rating |
Ind Code |
Rim Width & Flange |
Min. Dual Spacing | Approximate Inflated Dimensions | Loaded Dimensions |
Tread Depth |
Performance Capability (TKPH) |
Type | |||||||||
Overall Width | Overall Diameter | Static Load Rad | |||||||||||||||||
in | mm | in | mm | in | mm | in | mm | 32nds | mm | T1 | T2 | T3 | TT | TL | |||||
TL559S+ | ** | L-5 | 25.00/3.5 | 29.5 | 749 | 75.6 | 1921 | 31.8 | 807 | 126.0 | 100.0 | TL | |||||||
TL538S+ | * | L-5 | 25.00/3.5 | 29.5 | 749 | 75.6 | 1921 | 31.8 | 807 | 118.4 | 94.0 | TL | |||||||
TL538S+ | ** | L-5 | 25.00/3.5 | 29.5 | 749 | 75.6 | 1921 | 31.8 | 807 | 118.4 | 94.0 | TL | |||||||
29.5R25 | TB516 | * | L-3 | 25.00/3.5 | 29.5 | 749 | 73.8 | 1874 | 31.8 | 807 | 47.9 | 38.0 | TL | ||||||
TB516 | ** | L-3 | 25.00/3.5 | 29.5 | 749 | 73.8 | 1874 | 31.8 | 807 | 47.9 | 38.0 | TL | |||||||
TB598S | * | L-4 | 25.00/3.5 | 29.5 | 749 | 75.6 | 1921 | 71.8 | 57.0 | TL | |||||||||
TB598S | ** | L-4 | 25.00/3.5 | 29.5 | 749 | 75.6 | 1921 | 71.8 | 57.0 | TL | |||||||||
