Tire Size Designation |
Pattern |
Ply Rating |
Ind Code |
Rim Width & Flange |
Min. Dual Spacing | Approximate Inflated Dimensions | Loaded Dimensions |
Tread Depth |
Performance Capability (TKPH) |
Type | ||||||||||||||||||||||
Overall Width | Overall Diameter | Static Load Rad | ||||||||||||||||||||||||||||||
in | mm | in | mm | in | mm | in | mm | 32nds | mm | T1 | T2 | T3 | TT | TL | ||||||||||||||||||
15.5-25 | TL502 TL508 | 12PR 12PR | E-3 E-2/L-2 | 12.00/1.3 12.00/1.3 | 15.6 15.6 | 395 395 | 50.2 50.2 | 1275 1275 | 31.5 31.5 | 25.0 25.0 | TL TL | |||||||||||||||||||||
17.5-25 | TL508 TL516 TL612 TL612 | 12, 16PR 12, 16PR 12, 16PR 12, 16PR | E-2/L-2 L-3 E-3/L-3 E-3/L-3 | 14.00/1.5 14.00/1.5 14.00/1.5 14.00/1.5 | 17.5 17.5 17.5 17.5 | 445 445 445 445 | 53.1 53.1 53.1 53.1 | 1350 1350 1350 1350 | 31.5 32.8 32.1 32.8 | 25.0 26.0 26.0 25.5 | TL TT TT TL | |||||||||||||||||||||
10 KM/H (5 MPH) | 50 KM/H (30 MPH) | |||||||||||||||||||||||||||||||
15.5-25 | 275 40 | 300 44 | 325 47 | 350 51 | 375 54 | 400 58 | 225 33 | 250 36 | KPa PSI KG LBS | |||||||||||||||||||||||
4500 9900 | 4750 10500 | 4875 10700 | 5150 11400 | 5300 11700 | 5600(12) 12300(12) | 3000 6600 | 3250(12) 7150(12) | |||||||||||||||||||||||||
17.5-25 | 275 40 | 300 44 | 325 47 | 350 51 | 375 54 | 400 58 | 425 62 | 450 475 65 69 | 225 33 | 250 36 | 275 40 | 300 44 | KPa PSI KG LBS | |||||||||||||||||||
5300 11700 | 5600 12300 | 5800 12800 | 6150(12) 13600(12) | 6300 13900 | 6700 14800 | 6900 15200 | 7100 7300(16) 15700 16100(16) | 3650(12) 8050(12) | 3875 8550 | 4125 9100 | 4250(16) 9350(16) | |||||||||||||||||||||
