Tire Size Designation |
Pattern |
Star Rating |
Ind Code |
Rim Width & Flange |
Min. Dual Spacing | Approximate Inflated Dimensions | Loaded Dimensions |
Tread Depth |
Performance Capability (TKPH) |
Type | |||||||||
Overall Width | Overall Diameter | Static Load Rad | |||||||||||||||||
in | mm | in | mm | in | mm | in | mm | 32nds | mm | T1 | T2 | T3 | TT | TL | |||||
TB516 | * | L-3 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 40.3 | 32.0 | TL | |||||||
TB516 | ** | L-3 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 40.3 | 32.0 | TL | |||||||
TB516-II | * | L-3 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 40.3 | 32.0 | TL | |||||||
TL528 | * | L-3 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 50.4 | 40.0 | TL | |||||||
TL528 | ** | L-3 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 50.4 | 40.0 | TL | |||||||
23.5R25 | TM518 | * | L-2 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 37.8 | 30.0 | TL | ||||||
TM518 | ** | L-2 | 19.50/2.5 | 23.5 | 597 | 63.7 | 1617 | 28.3 | 720 | 37.8 | 30.0 | TL | |||||||
TL538S+ | * | L-5 | 19.50/2.5 | 23.5 | 597 | 65.9 | 1673 | 28.3 | 720 | 97.0 | 77.0 | TL | |||||||
TL538S+ | ** | L-5 | 19.50/2.5 | 23.5 | 597 | 65.9 | 1673 | 28.3 | 720 | 97.0 | 77.0 | TL | |||||||
TL559S+ | ** | L-5 | 19.50/2.5 | 23.5 | 597 | 65.9 | 1673 | 29.1 | 738 | 103.3 | 82.0 | TL | |||||||
TB516 | * | L-3 | 22.00/3.0 | 26.5 | 673 | 68.9 | 1750 | 30.5 | 775 | 44.1 | 35.0 | TL | |||||||
TB516 | ** | L-3 | 22.00/3.0 | 26.5 | 673 | 68.9 | 1750 | 30.5 | 775 | 44.1 | 35.0 | TL |
